Electrical Specifications | |
Frequency Range (MHz) | 698-960 |
Horizontal Half-power Beamwidth (°) | 360 |
Vertical Half-power Beamwidth (°) | 38 |
Gain (dBi) | 6 |
Polarization | Vertical |
VSWR | ≤2.0 |
Average Power, Maximum (W) | 50 |
Impedance (Ω) | 50 |
Mechanical Specifications | |
Dimensions (mm) | Φ75×680±10 |
Net Weight installation kit included (kg) | 1.2 |
Radome Material | Polycarbonate |
Radome Color | White |
Connector | N Female |
Connector Position | Bottom of Antenna |
Environmental Specifications | |
Application | Outdoor |
Operating Temperature (℃) | -40 to +70 (-40 to 158℉) |
Humidity (%) | 5 to 95 |
Survival Wind Velocity (km/h) | 200 |
Mounting Specifications | |
MOUNTING BRACKETS ARE INCLUDED UNLESS OTHERWISE SPECIFIED | |
Mounting Mast Diameter (mm) | Φ 50 to 90 |
